A milestone of microscopy history: The SALVE III microscope is completed and reaches a new world record


Figure 1. SALVE team reports completion of the SALVE III microscope.

Figure 2. Final adjustments at the SALVE microscope.

April 25, 2016 - Ulm University, FEI Company and CEOS GmbH announced today that they have finalized the SALVE III microscope. "We are truly excited by the successful completion which surpassed all our expectations the more since the SALVE microscope is the first of its kind. Our long-lasting efforts have paid off,” said Ute Kaiser, University of Ulm, head of the SALVE project. “We believe that our unique microscope will open the door to ground-breaking discoveries in the important class of electron-beam-sensitive materials”.

The SALVE project partners Ulm University, FEI Company, and CEOS GmbH have finalized the Sub-Angstrom Low-Voltage Electron (SALVE) microscope III. "With the completion of this instrument we have reached a key project objective (Fig. 1, 2). The new SALVE microscope has even surpassed by about 30% all required specifications for high-resolution imaging at 80, 60, 40, and 20 kV accelerating voltages. Now our application-related work starts, we are enormously curious to do further research on 2D materials, thin classical materials, and even single molecules, to learn how far we can reach into the sub-nanoworld. Our microscopy community is enriched by the dedicated spherically and chromatic aberration-corrected low-voltage TEM. We feel it is our responsibility, ambition, and great pleasure to explore its potential - in cooperation with the world-wide community", said Ute Kaiser.


Figure 3. View in the SALVE microscope.

Figure 5. SALVE team reports successful completion.

The FEI Titan Themis microscope's heart is CEOS's spherical and chromatic aberration corrector (Fig. 3). Max. Haider, director of the CEOS Company explains their new corrector: "To eliminate the chromatic aberrations occurring at low voltage, we have developed a corrector system over many years that accepts high opening angles and thus greatly improved the imaging mode. With this corrector we have now further advanced the limits of the instrument and the technique in aberration-corrected low-voltage transmission electron microscopy." "At 40 kV the instrument's resolution is 15 times the diffraction limiting electron wavelength", Harald Rose, member of the SALVE team, father of the practical-realizable aberration correction and Senior Professor at Ulm University, noticed happily. Thus, a new world record was reached.

The SALVE III TEM:

As images with sub-Angstrom resolution are now available at low operating voltages, dynamics can be studied atom-by-atom (Fig. 4).


CNT with fullerenes at 80 kV Cs/30 kV Cs/Cc

Figure 4: High-resolution transmission electron microscopy (HRTEM) images of C60 molecules (fullerenes) in single-walled carbon nanotubes. (left) image obtained in the spherical aberration-corrected FEI Titan at 80 kV, (right) image obtained in the spherical and chromatic aberration-corrected SALVE III TEM at 30 kV. The electron dose is 106 e-/nm2. Image: Johannes Biskupek.

Bert Freitag, FEI’s director of product marketing for Materials Science adds highlighting the excellent teamwork through the project: “We could not have developed this industry-leading microscope without the critical contributions of our partner CEOS and the close interaction with the University of Ulm."

Ute Kaiser and her team at Ulm University are also relieved that the transition from ZEISS to FEI Company went so constructive. FEI could deliver the microscope in record time of less than two years. To the foundation partner belongs the company ZEISS, which had to withdraw from the SALVE project because of strategic company decisions.

Part of the SALVE project is also a new microscopy-building at the University of Ulm, which will provide the necessary environment for the new SALVE instrument. This new building is financed by Ulm University and the State of Baden Wuerttemberg with about 2 Million Euros and the public utility company in Ulm with another 1.6 million Euros. Until the move of the SALVE III microscope into the new microscopy building, which is scheduled for September 2017, experiments with the SALVE III TEM will be conducted in Heidelberg at the CEOS Company.

"We are very proud that with the completion of the SALVE III microscope we have succeeded to write a piece of ‘microscopy history’ and to build on the approach set out in Darmstadt by Otto Scherzer in the field of aberration-corrected electron microscopy”, the SALVE researchers and developers state. With his pioneering papers from 1936 to 1979, Otto Scherzer had created the framework for the SALVE project, not only concerning the fundamentals of aberration correction but also regarding the reduction of radiation damage and the imaging of sensitive materials in electron microscopy.

The SALVE project, promoted by the German Research Foundation (DFG) and the Ministry of Science, Research and the Arts Baden-Wurttemberg Germany, started in late 2008. Now, the team reported the successful completion of the SALVE III microscope to representatives of the funding organizations (B. Jahnen (DFG), V. Kuntze (MWK-BW), Fig. 5), the chancellor of Ulm University (D. Kaufmann), and to members of the advisory board (J. Mayer, P. Karnthaler, H. Lichte).
